Coupling Straight Tail

Coupling series especially developed for connecting coolant lines on injection moulds. Fully interchangeable with other brands with the same plug profiles. All dimensions and tolerances according to original specs. 15 bar, maximum static working pressure with safety factor of 4 to 1.
NameValveØ (mm)L (mm)L1 (mm)A (mm)D (mm)Qty (pcs)
09K10Vyes65222101810
09K10no65222101810
09K13Vyes65222131810
09K13no65222131810
13K10Vyes96125102310
13K10no96125102310
13K13Vyes96125132310
13K13no96125132310
19K19Vyes139032193210
19K19no139032193210
